Introduction

Over the years I've also been collecting data on modern (post WWII) aircraft carrier designs as well and based on this data, in combination with the data that I have also collected on surface combatants, I have put together a spreadsheet for developing early stage notional designs for aircraft carriers.

Much of the weight data that I have used comes from Dr. Norman Freidman's book on "US Aircraft Carriers" general internet searches and as well as some of the MIT Theses that I have referenced for  Surface Combatants.

In general this spreadsheet is set up somewhat similar to the spreadsheets that I am developing for modern durface combatants, though here I am trying to put as much as I can into a single spreadsheet rather than having separate workbooks for pre-processing, doing the main calculations, and post-processing.

A link to the latest version of this spreadsheet can be found at this link.

General Spreadsheet Layout

In general the spreadsheet is set up as follows (please click links below for more info on each section):

• the colored tabs up front in the spreadsheet are general stuff,
• the  colored tabs will eventually contain instructions etc, the,
• the  colored tabs address defining the airgroup,
• the  colored tabs are for preliminary ship sizing,
• the  colored tabs are for flight deck layout,
• the  colored tabs are for powering estimates,
• the  colored tabs cover the primary weight estimating,
• the  colored tabs cover the hullform development,
• the  colored tabs are calcs that support the hullform development,
• the  colored tabs are for cost estimating,
• the  colored tab contains a summary of the results of all the calculations
• the  colored tabs are just for storage of some information that I am trying to figure out how to incorporate,
• the  colored tabs (at the end of the spreadsheet) will eventually be used to help in the transfer of data to some other spreadsheets.

• any  shaded cells are items where the spreadsheet will make an estimate,
• any shaded cells are items are items where the user can over ride this suggested value are identified,
• any shaded cells represent the results of calcs which have been repeated again for reference, and
• any  shaded cells are typically data used in the calcs that may still need to be verified.
